Project Description

Multi-Cable Cutter Klein-Kurve

63020

  • Hardened steel precision-ground cutting blades for long life
  • Copper curved cutter cleanly cuts round copper cable without compression or frayed ends
  • Anvil cutter for solid and stranded copper wire up to 12 AWG and stainless steel up to .032-Inch (0.8 mm) diameter
  • Mild steel cutter for conductors up to .080-Inch (2 mm) diameter
  • Curved cutter for solid and stranded copper wire up to 8 AWG, multi-conductor cable up to 1/2-Inch (13 mm) diameter and coaxial cable RG-6 Quad, RG-59, and RG-62
  • New lock design prevents accidental locking or loosening over time
  • Double-dipped grips for comfort
  • Coil spring provides fast self-opening action
  • Holes for looping and bending wire

多线切割机Klein-Kurve

63020

  • 硬化钢精密研磨切割刀片,使用寿命长
  • 铜弯曲刀具干净地切割圆形铜缆,没有压缩或磨损的末端
  • 铁砧刀具,适用于高达12 AWG的实心和绞合铜线,以及直径小于.032英寸(0.8 mm)的不锈钢
  • 适用于直径小于.080英寸(2毫米)的导体的低碳钢铣刀
  • 弯曲刀具,适用于高达8 AWG的实心和绞合铜线,直径达1/2英寸(13 mm)的多芯电缆和同轴电缆RG-6 Quad,RG-59和RG-62
  • 新的锁定设计可防止意外锁定或松动
  • 双浸手柄,舒适
  • 线圈弹簧提供快速自动开启动作
  • 用于环绕和弯曲线的孔

The Klein Tools Klein-Kurve Multi-Cable Cutter has a wide range of blades designed to cut multiple types of cable. The anvil cutter cuts 12 AWG copper wire and stainless steel up to 0.032-Inch in diameter. The copper curved cutter cuts 8 AWG solid and 6 AWG stranded copper wire, conductors, and coaxial cable. This tool also has a cutter for mild steel.

Specifications
Cutting Capacity:
Up to 12 AWG Solid and Stranded Copper Wire, Up to 0.032” (.081 mm) Diameter Stainless Steel, Up to 1/2” (12.7 mm) Multi-conductor Cable, Coaxial Cable RG-6 Quad, RG-59 and RG-62
Application:
Cuts Copper Wire, Stainless Steel, Conductors, and Coaxial Cable
Screw Shearing:
6-32 & 8-32
Material:
Steel
Handle Color:
Red
Overall Length:
7” (177.8 mm)
Weight:
0.44 lb (0.20 kg)
UPC:
092644630200
WARNINGS
  • Always wear approved eye protection.
  • NOT insulated. Plastic-dipped or slip-on plastic handles are NOT intended for protection against electrical shock.

Klein Tools Klein-Kurve多功能电缆剪具有多种刀片,可用于切割多种类型的电缆。铁砧切割机切割12 AWG铜线和不锈钢直径达0.032英寸。铜弯曲切割器切割8 AWG实心和6 AWG绞合铜线,导体和同轴电缆。该工具还有一个用于低碳钢的刀具。

产品规格
切割能力:
高达12 AWG实心和多股铜线,最大0.032英寸(0.081毫米)直径不锈钢,最大1/2英寸(12.7毫米)多芯电缆,同轴电缆RG-6四通道,RG-59和RG-62
应用:
切割铜线,不锈钢,导体和同轴电缆
螺丝剪切:
6-32和8-32
材料:
处理颜色:
红色
总长度:
7”(177.8 mm)
重量:
0.44磅(0.20千克)
UPC:
092644630200
警告
  • 始终佩戴认可的护目镜。
  • 没有绝缘。塑料浸渍或滑动塑料手柄不用于防止电击。
