Electrical Maintenance and Test Kit

CL110KIT

  • Measure AC current via the clamp, and AC/DC voltage, resistance and continuity via test leads
  • Detects the most common wiring problems in standard and GFCI receptacles including open ground, reverse polarity, open hot, open neutral and hot/ground reversed
  • Line splitter allows the measuring of current draw up to 15A without splitting the load’s power cord
  • CAT III 600V, Class 2, Double insulation safety rating
  • AC Auto-Ranging 400 amp digital clamp meter
  • Backlit display for clear readings
  • Includes a case, test leads and batteries

电气维护和测试套件

CL110KIT

  • 通过钳位测量交流电流，通过测试引线测量AC / DC电压，电阻和连续性
  • 检测标准和GFCI插座中常见的接线问题，包括开路接地，反极性，开路热，开路中性和热/地反转
  • 分线器允许在不分离负载电源线的情况下测量高达15A的电流
  • CAT III 600V，Class 2，双重绝缘安全等级
  • AC Auto-Ranging 400安培数字钳形表
  • 背光显示屏，清晰读数
  • 包括外壳，测试引线和电池

Klein Tools Clamp Meter Kit includes the CL110 400A Auto-Ranging Digital Clamp Meter, RT210 GFCI Receptacle Tester and 69409 Line Splitter 10x. The kit allows for easy testing of live circuits and measuring of current and voltage. The kit includes a carrying pouch, test leads and batteries.

Specifications
Application:
Testing and Measuring Voltage
Special Features:
Backlit Display For Clear Readings
Overall Length:
3.016” (76.6 mm)
Overall Height:
8.703” (221.1 mm)
Overall Width:
1.609” (40.9 mm)
Batteries:
3 x AAA
Drop Protection:
3.3 ft (1 m)
Display:
Backlit
Pollution Degree:
8.7”
Standard:
CAT III 600V
Included:
Test Leads, Batteries, Carrying Case
Weight:
0.94 lb (0.43 kg)
UPC:
092644690563
WARNINGS
  • Do not attempt to measure resistance or continuity on live circuits.
  • Read, understand and follow all instructions, cautions and warnings attached to and /or packed with all test and measurement devices before each use.
  • Before each use verify meter operation by measuring a known voltage or current.
  • Do not use the meter during electrical storms or in wet weather, and do not use the meter or test leads if they appear to be damaged.

Klein Tools Clamp Meter Kit包括CL110 400A自动测距数字钳形表，RT210 GFCI插座测试仪和69409 Line Splitter 10x。该套件可以轻松测试带电电路并测量电流和电压。该套件包括一个携带袋，测试导线和电池。

产品规格
应用：
测试和测量电压
特殊功能：
背光显示清晰读数
总长度：
3.016”（76.6 mm）
总体高度：
8.703”（221.1 mm）
总宽度：
1.609”（40.9 mm）
电池：
3 x AAA
掉落保护：
3.3英尺（1米）
显示：
背光
污染程度：
8.7 ”
标准：
CAT III 600V
包括：
测试引线，电池，便携包
重量：
0.94磅（0.43千克）
UPC：
092644690563
警告
  • 不要试图测量带电电路的电阻或连续性。
  • 在每次使用之前，请阅读，理解并遵守所有测试和测量设备附带和/或包装的所有说明，注意事项和警告。
  • 在每次使用之前，通过测量已知电压或电流来验证仪表操作。
  • 在暴风雨或潮湿天气期间请勿使用仪表，如果仪表或测试导线看起来已损坏，请勿使用。
