数字钳形表，交流自动量程400 Amp，带温度

CL220

  • 通过钳位和AC / DC电压测量AC电流和NCVT，通过测试引线测量电阻和导通性，并通过热电偶测量温度
  • 夹钳中集成了非接触式电压测试仪
  • 背光LCD便于在弱光下观看
  • 自动调整真均方根（TRMS）测量技术的准确性
  • 夹具侧面的测试导线支架和用于仪表（目录号69445或69417）的可选磁性吊架，用于免提操作
  • 用K型热电偶探头测量温度
  • 自动量程，保持，数据保持和至大值
  • 10分钟后自动关闭电源以延长电池寿命
  • 包括一个手提箱，带CAT III / CAT IV安全帽的测试线，热电偶，说明和3节AAA电池
  • 电池电量低指示器和易于接近的电池仓
  • 能够承受6.6英尺（2 m）的跌落
  • CAT III 600V，等级2，双重绝缘安全等级
  • 满足在基本和受控电磁环境（例如住宅，办公室和轻工业场所）中使用的要求

Digital Clamp Meter, AC Auto-Ranging 400 Amp with Temp

CL220

  • Measures AC current and NCVT via clamp and AC/DC voltage, resistance, and continuity via test-leads, and temperature with thermocouple
  • Non-contact voltage tester integrated into the clamp jaw
  • Backlit LCD for ease of viewing in low light
  • Automatically ranging True Root Mean Squared (TRMS) measurement technology for accuracy
  • Test lead holder on side of clamp and optional magnetic hanger for meter (Cat. Nos. 69445 or 69417) for hands free operation
  • Measures temperature with a K-Type thermocouple probe
  • Auto-Range, Hold, Data Hold, and Max value
  • Auto-power off after 10 minutes to conserve battery life
  • Includes a carrying case, test leads with CAT III/CAT IV safety caps, thermocouple, instructions, and 3 x AAA batteries
  • Low battery indicator and easily accessible battery compartment
  • Built to withstand a 6.6-Foot (2 m) drop
  • CAT III 600V, Class 2, Double insulation safety rating
  • Meets requirements for use in basic and controlled electromagnetic environments like residential, office and light-industrial locations

CL2200通过钳位和AC / DC电压测量AC电流和NCVT，通过测试引线测量电阻和导通性，并通过热电偶测量温度。仪表具有自动量程的真均方根（TRMS）测量技术，可确保准确性。此外，背光LCD使在弱光下观看变得容易。

技术指标
类型：
带温度的自动量程TRMS钳位
应用：
通过钳位测量AC电流和NCVT，通过测试引线测量AC / DC电压，电阻和连续性，并通过热电偶测量温度
特殊功能：
自动调整真均方根（TRMS）测量技术的准确性；NCVT；附加温度
材料：
ABS /电子
电池：
3 x AAA
自动关机：
是
钳口尺寸：
1.61英寸（4.1厘米）
跌落保护：
6.6’（2 m）
显示：
2000点背光LCD
功能：
TRMS，交流电流，NCVT，交流/直流电压，电阻，连续性和温度
电压：
600 V交流/直流
当前：
交流400 A
欧姆（电阻）：
20MΩ
交流电压
600伏
直流电压
600伏
直流极性指示器：
是
温度范围：
-40°-1832°F（-40°-1000°C）
标准：
CATIII 600V，2级，双重绝缘安全等级，CE认证
包括：
手提箱，说明，测试线，热电偶和电池
总长度：
8.45英寸（21.5厘米）
总高度：
1.51英寸（3.8厘米）
总宽度：
3.51英寸（8.9厘米）
重量：
11盎司（314克）
UPC：
092644692857
警告事项
  • 每次使用前，请阅读，理解并遵守所有测试和测量设备随附和/或包装的所有说明，警告和警告。
  • 请勿尝试测量带电电路的电阻或连续性。
  • 每次使用前，请通过测量已知的电压或电流来验证电表的运行。
  • 请勿在雷雨天气或潮湿天气中使用仪表，并且如果仪表或测试线看起来已损坏，也不要使用仪表。
  • 以非制造商指定的方式使用本仪表会损害安全操作，导致严重的人身伤害甚至死亡。

The CL2200 measures AC current and NCVT via clamp and AC/DC voltage, resistance, and continuity via test-leads, and temperature with thermocouple. The meter features automatically ranging True Root Mean Squared (TRMS) measurement technology for accuracy. Additionally, a backlit LCD makes viewing in low light easy.

Specifications
Type:
Auto Ranging TRMS Clamp with Temperature
Application:
Measures AC Current and NCVT via Clamp and AC/DC Voltage, Resistance, and Continuity via Test-leads, and Temperature with Thermocouple
Special Features:
Automatically Ranging True Root Mean Squared (TRMS) Measurement Technology for Accuracy; NCVT; Added Temperature
Material:
ABS/Electronics
Batteries:
3 x AAA
Auto-Power Off:
Yes
Jaw Size:
1.61” (4.1 cm)
Drop Protection:
6.6′ (2 m)
Display:
2000 Count Backlit LCD
Functions:
TRMS, AC Current, NCVT, AC/DC Voltage, Resistance, Continuity and Temperature
Voltage:
600 V AC/DC
Current:
400 A AC
Ohms (Resistance):
20 M?
AC Voltage:
600 V
DC Voltage:
600 V
DC Polarity Indicator:
Yes
Temperature Range:
-40° – 1832°F (-40° – 1000°C)
Standard:
CATIII 600V, Class 2, Double Insulation Safety Rating, CE Certified
Included:
Carrying Case, Instructions, Test Leads, Thermocouple, and Batteries
Overall Length:
8.45” (21.5 cm)
Overall Height:
1.51” (3.8 cm)
Overall Width:
3.51” (8.9 cm)
Weight:
11 oz (314 g)
UPC:
092644692857
WARNINGS
  • Read, understand and follow all instructions, cautions and warnings attached to and /or packed with all test and measurement devices before each use.
  • Do not attempt to measure resistance or continuity on live circuits.
  • Before each use verify meter operation by measuring a known voltage or current.
  • Do not use the meter during electrical storms or in wet weather, and do not use the meter or test leads if they appear to be damaged.
  • Usage of this meter in any way other than that specified by the manufacturer can impair safe operation, resulting in severe injury or death.
