Project Description

Web-Strap Ratchet Hoist

KN1500PEX

  • Large, non-conductive dial (drum knob) allows web slack to be adjusted with ease
  • 360-degree handle rotation
  • 3/4-ton single line and 1-1/2-ton double line load rating
  • Tight ratcheting mechanism allows precise tensioning

Web-Strap棘轮式提升机?紧线器

KN1500PEX

  • 大而不导电的表盘(鼓旋钮)可以轻松调节纸幅松弛
  • 360度手柄旋转
  • 3/4吨单线和1-1 / 2吨双线额定负载
  • 紧密的棘轮机构允许精确张紧

Klein Tools’ Web-Strap Ratchet Hoist features a tighter ratchet to reduce work and fatigue. The handle and drum knob allow you to safely control the tension release to avoid free wheeling. The hoist can be used in both a single line and double line configuration. The handle provides a 360 degree range of motion for easier adjustment from any angle.

Specifications
Single Line Pulling Distance:
20” to 138” (50.5 to 350.5 cm)
Single Line Load Rating:
1500 lb (680 kg)
Double Line Pulling Distance:
26” to 79” (66.0 to 200.6 cm)
Double Line Load Rating:
3000 lb (1361 kg)
Weight:
12.5 lb (5.7 kg)
UPC:
092644614255
WARNINGS
  • Read, understand, and follow all warnings, cautions, safety information, and instructions in the manual before operating or servicing this hoist.

Klein Tools的Web-Strap棘轮式提升机具有更紧凑的棘轮,可减少工作和疲劳。手柄和鼓旋钮可让您安全地控制张力释放,以避免自由旋转。提升机可用于单线和双线配置。手柄提供360度的运动范围,可从不同角度轻松调节。

产品规格
单线拉距:
20”到138”(50.5到350.5厘米)
单线额定载荷:
1500磅(680千克)
双线拉距离:
26”到79”(66.0到200.6厘米)
双线额定载荷:
3000磅(1361千克)
重量:
12.5磅(5.7千克)
UPC:
092644614255
警告
  • 在操作或维修此提升机之前,请阅读,理解并遵守本手册中的所有警告,注意事项,安全信息和说明。
