Dual Range Non-Contact Voltage Tester

NCVT-2

  • Automatically detects and indicates low voltage (12-48V AC) and standard voltage (48-1000V AC) allowing broad application
  • Non-contact detection of standard voltage in cables, cords, circuit breakers, lighting fixtures, switches, outlets and wires
  • Non-contact detection of low voltage in security, entertainment, communications, environmental control, and irrigation systems
  • High intensity, bright green LED indicates the tester is operational and aids in illuminating the workspace
  • Dual Range testing, select 12-1000V AC or 48-1000V AC
  • Auto power-off feature conserves and extends battery life
  • CAT IV 1000 Volt rating provides expanded operation and protection
  • Lightweight, durable polycarbonate plastic resin construction; convenient pocket clip
  • 9.8 ft / 3 m drop protection
  • Safety Rating: CAT IV 1000V

双量程非接触式电压测试仪

NCVT-2

  • 自动检测并指示低电压(12-48V AC)和标准电压(48-1000V AC),允许广泛应用
  • 非接触式检测电缆,电线,断路器,照明装置,开关,插座和电线中的标准电压
  • 安全,娱乐,通信,环境控制和灌溉系统中的低电压非接触式检测
  • 高强度,亮绿色LED指示测试仪可操作并有助于照亮工作空间
  • 双量程测试,选择12-1000V AC或48-1000V AC
  • 自动关机功能可以节省电池并延长电池寿命
  • CAT IV 1000伏额定值提供扩展的操作和保护
  • 轻质耐用的聚碳酸酯塑料树脂结构;?方便的口袋夹
  • 9.8英尺/ 3米跌落保护
  • 安全等级:CAT IV 1000V

This Dual-Range Non-Contact Voltage Tester automatically detects low voltage and standard voltage. A bright green LED will tell you the tester is working and also functions as a worklight. The light flashes red and two distinct warning tones sound when either low or standard voltage is detected.

Specifications
Special Features:
50 – 500 Hz Low-Pitched Pulsing Beeping Sound; Blue LED Turns Off and Red LED Blinks (Approximately 2x Per Second)
Drop Protection:
9.8 ft (3 m)
Voltage:
12 – 1000V AC
Frequency:
50 – 500 Hz
Pollution Degree:
2
Standard:
CAT IV 1000V
Included:
(2) Alkaline 1.5V AAA Batteries
Weight w/Batteries:
1.6 oz (45 g)
Batteries:
2 x AAA
Overall Length:
5.5” (139.7 mm)
Overall Height:
1” (25.4 mm)
Overall Width:
0.719” (18.3 mm)
Weight:
0.80 oz (22.7 g)
UPC:
092644690020
WARNINGS
  • Read, understand, and follow all warnings, cautions, safety information, and instructions in the manual before operating or servicing this tester. Failure to follow instructions could result in death or serious injury.
  • Never assume neutral or ground wires are de-energized. Neutrals in multi-wire branch circuits may be energized when disconnected and must be retested before handling.

这种双量程非接触式电压测试仪可自动检测低压和标准电压。一个明亮的绿色LED将告诉您测试仪正在工作,也可以作为工作灯。当检测到低电压或标准电压时,指示灯呈红色闪烁,并发出两种不同的警告音。

产品规格
特殊功能:
50 – 500 Hz低音脉冲蜂鸣声;?蓝色LED熄灭,红色LED闪烁(大约每秒2x)
掉落保护:
9.8英尺(3米)
电压:
12 – 1000V AC
频率:
50 – 500赫兹
污染程度:
2
标准:
CAT IV 1000V
包括:
(2)碱性1.5V AAA电池
电池重量:
1.6盎司(45克)
电池:
2 x AAA
总长度:
5.5英寸(139.7毫米)
总体高度:
1”(25.4 mm)
总宽度:
0.719”(18.3 mm)
重量:
0.80盎司(22.7克)
UPC:
092644690020
警告
  • 在操作或维修此测试仪之前,请阅读,理解并遵守本手册中的所有警告,注意事项,安全信息和说明。不遵守指示可能导致死亡或严重伤害。
  • 切勿假设中性线或接地线断电。多线分支电路中的中性线可以在断开时通电,并且必须在处理之前重新测试。
