Non-Contact Voltage Tester w/Infrared Thermometer

NCVT-4IR

  • Designed specifically for HVAC applications
  • Provides non-contact determination of AC voltage in cables, cords, circuit breakers, switches, outlets and wires, as well as AC voltage in security, entertainment, communications, environmental control, and irrigation systems
  • Detects AC voltage from 12 to 1000V with visual and audible indicators
  • IR thermometer with user selectable °F / °C from -22 to 482°F (-30 to 250°C)
  • Convenient laser pointer also helps target 4:1 distance to spot ratio for IR temperature
  • Backlit LCD display with 0.1 degree resolution
  • Auto power-off conserves and extends battery life
  • Screw-thread battery cap with O-ring ensures dust and water resistance
  • Lightweight, compact tool with pocket clip provides easy storage and quick access

非接触式电压测试仪带红外线温度计

NCVT-4IR

  • 为HVAC应用而设计
  • 提供非接触式确定电缆,电线,断路器,开关,插座和电线中的交流电压,以及安全,娱乐,通信,环境控制和灌溉系统中的交流电压
  • 通过视觉和听觉指示器检测12至1000V的交流电压
  • IR温度计,用户可在-22到482°F(-30到250°C)之间选择°F /°C
  • 方便的激光指示器还有助于在红外温度下实现4:1的距离与光斑比
  • 背光LCD显示屏,分辨率为0.1度
  • 自动关机可以节省电池并延长电池寿命
  • 带O形圈的螺纹电池盖可确保防尘和防水
  • 轻巧紧凑的工具,带有口袋夹,便于存放和快速访问

The NCVT-4IR provides non-contact determination of AC voltage in cables, cords, circuit breakers, switches, outlets and wires; as well as infrared (IR) thermometer measurements, making it the perfect choice for HVAC professionals.

Specifications
Type:
Non-Contact
Application:
HVAC
Special Features:
High-Pitched Continuous Beeping Sound
Voltage:
12 – 1000V AC
Frequency:
50 – 500 Hz
Ingress Protection:
54
Standard:
CAT IV 1000V
Included:
Batteries
Weight w/Batteries:
2.8 oz (79 g)
Batteries:
2 x AAA
Battery Life:
Average: 134 Hours; Continuous IR: 64 Hours
Overall Length:
6.25” (158.8 mm)
Overall Height:
1.25” (31.8 mm)
Overall Width:
1.188” (30.2 mm)
Weight:
2.0 oz (57 g)
UPC:
092644690617
WARNINGS
  • Do not direct laser beam into eyes, as this can cause permanent eye damage.
  • Read, understand, and follow all instructions, cautions and warnings attached to and/or packed with all Test & Measurement devices before each use.

NCVT-4IR提供电缆,电线,断路器,开关,插座和电线中交流电压的非接触式测定;?以及红外(IR)温度计测量,使其成为HVAC专业人士的选择。

产品规格
类型:
非接触式
应用:
HVAC
特殊功能:
高音持续哔哔声
电压:
12 – 1000V AC
频率:
50 – 500赫兹
入侵保护:
54
标准:
CAT IV 1000V
包括:
电池
电池重量:
2.8盎司(79克)
电池:
2 x AAA
电池寿命:
平均:134小时;?连续红外线:64小时
总长度:
6.25”(158.8 mm)
总体高度:
1.25英寸(31.8毫米)
总宽度:
1.188”(30.2 mm)
重量:
2.0盎司(57克)
UPC:
092644690617
警告
  • 不要将激光束引入眼睛,因为这会造成永久性的眼睛损伤。
  • 在每次使用之前,请阅读,理解并遵守所有测试和测量设备附带和/或包装的所有说明,注意事项和警告。
