Proximity Voltage Detector
The PRX-4 Proximity Voltage Detector provides utility professionals, arborists and first responders with a safety tool that will alert them to potentially dangerous high voltage in their work areas. The PRX-4 is a non contact detector with two voltage ranges:
- 50V – 4kV, 3” (8cm) detection range
- 4kV – UP, 10” (25cm) detection range
The PRX-4 utilizes a rugged, durable, water resistant housing with dual hotstick connections – universal spline and shotgun stick. All of this is achieved while weighing less than 1 pound (.45kg).
Proximity Voltage Detector?Features
- Sealed to resist water penetration in typical outdoor environments
- Two voltage ranges from 50V to 4kV and above 4kV
- Detects voltages typically 3” (8cm) from the source at the 50V setting and 4kV at 10” (25cm) at the 4kV setting
- Higher voltages result in greater detection distances
- Rechargeable battery with quick recharge – 15 minutes for a full day of use
- Heartbeat signal assures that the PRX is ready to detect voltage
- Rugged, durable housing
- Dual hotstick connections – universal spline & shotgun stick
- Loud beeper and LED lights indicate voltage
- Weighs less than 1 pound (0.45 kg)
- Easy to use electronic touch pad with large buttons
- Can be used on 50Hz and 60Hz systems
HD Electric Company is committed to ongoing review and improvement of its product lines, and thus reserves the right to modify product design and specifications without notice.
接近电压检测器
PRX-4接近电压检测器为公用事业专业人士,树木工人和急救人员提供安全工具,以提醒他们工作区域中存在潜在危险的高压。PRX-4是一种非接触式探测器,具有两个电压范围:
- 50V – 4kV,3“(8cm)检测范围
- 4kV – UP,10“(25cm)检测范围
PRX-4采用坚固耐用的防水外壳,带有双热杆连接 – 通用花键和操作杆。所有这一切都是在重量不到1磅(.45千克)的情况下实现的。
接近电压检测器功能
- 密封以抵抗典型户外环境中的水渗透
- 两个电压范围为50V至4kV,高于4kV
- 在50V设置下检测电压通常为3“(8cm),在4kV设置下检测10”(25cm)时4kV的电压
- 电压越高,检测距离越大
- 可充电电池,快速充电 – 一整天使用15分钟
- 心跳信号确保PRX准备好检测电压
- 坚固耐用的外壳
- 双热键连接 – 通用花键和猎枪棒
- 大声蜂鸣器和LED灯指示电压
- 重量不到1磅(0.45千克)
- 易于使用的电子触摸板与大按钮
- 可用于50Hz和60Hz系统
HD Electric Company致力于不断审查和改进其产品线,因此保留修改产品设计和规格的权利,恕不另行通知。
PRX系列非接触式验电器
PRX系列非接触式验电器体积轻巧,便于携带。无需接触带电导体即可达到验电功能,在现场作业尤其是需要连接长距离绝缘杆时,便于作业人员轻松作业。同时,每款PRX产品均有若干个电压量程,可以由用户自行选择需要检验的电压。该系列验电器已经获得中国电力科学研究院电力工业电气设备质量检验测试中心认证,安全性能,电气性能以及验电功能均符合国家相关标准。
PRX系列包含以下型号:
PRX-500(Z高量程500KV)
PRX-69D(Z高量程69KV)
PRX-35D(Z高量程35KV)
PRX-4(4KV以下和4KV以上,自动量程)
产品特点:
多量程电压选择
声光报警指示电压
可用于50/60Hz电力系统
快速充电,充电15分钟BZ一天使用
可通过市电或车载电源充电
可配合标准绝缘杆使用
PRX非接触式验电器参数表
PRX-500 | PRX-35D | PRX-4 | PRX-69D | |
电压量程 | 220(380)V/10KV/35KV/110KV/ 220KV/330KV/500KV | 220(380)V/10KV/35KV | 50-4KV/4KV 以上 | 120V/4KV/15KV/25 KV /35 KV /46 KV /69 KV |
自动量程 | 否 | 否 | 是 | 否 |
报警距离 | 25cm(典型值,4KV 以上电压) | |||
电池使用寿命 | 验电>200 次(满电),电池充满时间 3 小时 | |||
重量 | <0.45kg |
PRX非接触式验电器选型表
套装型号 | 套装详细配置 |
PRX-500/220P? | PRX-500(1)/PRX-HS(1)/PRX-CORD(1)/PRX-XF(1)/PRX-CS(1) |
PRX-69D/220P | PRX-69D(1)/PRX-HS(1)/PRX-CORD(1)/PRX-XF(1)/PRX-CS(1) |
PRX-35D/220P | PRX-35(1)/PRX-HS(1)/PRX-CORD(1)/PRX-XF(1)/PRX-CS(1) |
PRX-4/220P | PRX-4(1)/PRX-HS(1)/PRX-CORD(1)/PRX-XF(1)/PRX-CS(1) |
